ENGINE
- Type: 3-cylinder, Liquid-cooled, Diesel, Turbocharged, CRDI
- Model (Tier 4): L3C19-T
- Engine HP (Gross): 57.0
- PTO HP: 48.4
- Rated Speed (RPM): 2,600
- Displacement (cu in.): 114.7
- Fuel Tank Capacity (gal): 12.4
- Alternator (V-A): 12V - 70
DRIVE TRAIN
- Transmission: HST
- No. of Speeds: 3 Ranges
- Brakes: Wet, Multi-disc
- Steering: Hydrostatic Power Steering
PTO
- Type: Independent
- Rear PTO: Standard (540RPMS)
HYDRAULIC SYSTEM
- Implement pump (gpm): 8.2
- Steering pump (gpm): 6.8 Hydro Cab
- Total flow (gpm): 15.0 Hydro Cab
- Category, 3 pt hitch: CAT 2
- Hitch Lift capacity (lb): 2,755
- Remote Valves: 2 PAIR (1 DETENT, 1 STD)
DIMENSION
- Overall length, Bumper to link (in.): 133
- Wheelbase (in.): 73.2
- Overall width with tires (in.): 62.5
- Height to top of rops (in.): 90 Cab
TIRE SIZE
- Ag (Front / Rear): 9.5 – 16 / 13.6 – 24
- IND (Front / Rear): 12 – 16.5 / 17.5L – 24
- Turf Tire (Front / Rear) 28 x 8.5 – 15 / 41 x 14 – 20
WEIGHT
- Total weight without ballast (lbs.): 4,446
