ENGINE
- Type: 3-cylinder, Liquid-cooled, Diesel, CRDI
- Model (Tier 4): Yanmar 3TNV88
- Engine HP (Gross): 31.7
- PTO HP: 26.2
- Rated Speed (RPM): 2,600
- Displacement (cu in.): 100.2
- Fuel Tank Capacity (gal): 10.6
- Alternator (V-A): 12V - 50
DRIVE TRAIN
- Transmission Type : Hydrostatic Drive (Linked Pedal)
- No. of Speed : 3 Ranges
- Brakes: Wet, Multi-disc
- Steering : Hydrostatic Power Steering
PTO
- Type: Independent
- Rear PTO: Standard (540 rpm)
HYDRAULIC SYSTEM
- Implement pump (gpm): 6.7
- Steering pump (gpm): 5.0
- Total flow (gpm): 11.7
- Category, 3 pt hitch: CAT 1
- Hitch lift Capacity (lbs.) (Hitch End): 1,808
- Lift control type: Position
DIMENSION
- Overall length (Frame to Link, in.): 125
- Overall width with tires (in.): 66
- Wheelbase (in.): 69
- Height to top (in.): 90
TIRE SIZE
- Ag Front/Rear: 7 - 14 / 11.2 - 24
- IND Front/Rear: 27x8.50-15 / 43x16.00-20
- VT Front/Rear: 27x8.50-15 / 43x16.00-20
- HYB Front/Rear: 27x8.50-15 / 43x16.00-20
- Turf Front/Rear: 25x8.50-14 / 41x14.00-20
WEIGHT
- Total weight without ballast (lbs.) : 3,609
