ENGINE
- Type: 3 Cylinder, Liquid-cooled, Diesel, NA, IDI
- Model (Tier 4): MHI
- Engine HP (Gross) : 24.4
- PTO HP: 19
- Rated Speed (RPM): 2,400
- Displacement (cu. in): 100.4
- Fuel Tank Capacity (gal) : 11.4
- Alternator (V-A) : 12V – 55 Amps
DRIVE TRAIN
- Transmission Type : HST
- No. of Speed : 3 Ranges
- Brakes: Wet, Multi-disc
- Steering : Hydrostatic Power Steering
PTO
- Type: Independent
- Rear, rpm: 540 (Standard)
HYDRAULIC SYSTEM
- Control System: Position
- Implement pump (gpm): 6.1
- Steering pump (gpm): 4.6
- Total flow (gpm) : 10.7
- Category, 3 pt hitch: CAT I
- Hitch Lift capacity, lbs (Hitch end): 1,808
- Remote Valves: 1 Pair
DIMENSION
- Overall length (Frame to Link, in.): 125
- Overall width with tires (in.): 66
- Wheelbase (in.): 69
- Height to top (in.): 90
TIRE SIZE
- VT Front / Rear: 27X8.50-15 / 43X16.00-20
WEIGHT
- Total weight without ballast (lbs.) : 3,609
