ENGINE
- Type: 3 Cylinder, Liquid-cooled, Diesel, NA, IDI
- Model (Tier 4): MHI
- Engine HP (Gross) : 24.6
- PTO HP: 17.1
- Rated Speed (RPM): 2,500
- Displacement (cu. in): 80.4
- Fuel Tank Capacity (gal) : 10.6
- Alternator (V-A) : 12V – 50 Amps
DRIVE TRAIN
- Transmission Type : HST
- No. of Speed : 3 Ranges
- Brakes: Wet, Multi-disc
- Steering : Hydrostatic Power Steering
PTO
- Type: Independent
- Rear, rpm: 540 (Standard)
HYDRAULIC SYSTEM
- Control System: Position
- Implement pump (gpm): 7.1
- Steering pump (gpm): 4.6
- Total flow (gpm) : 11.7
- Category, 3 pt hitch: CAT I
- Hitch Lift capacity, lbs (Hitch end): 1,808
- Remote Valves: Option
DIMENSION
- Overall length (Frame to Link, in.): 119
- Overall width with tires (in.): 66
- Wheelbase (in.): 66
- Height to top (in.): 95
TIRE SIZE
- IND Front / Rear: 27X8.50-15 / 43X16.00-20
- VT Front / Rear: 27X8.50-15 / 43X16.00-20
WEIGHT
- Total weight without ballast (lbs.) : 3,007
