- 4WD (Front Wheel Mechanical Assist) – The MT125-24.7HP Sub-Compact Tractor features 4WD so you can get all your heavy duty pulling with no scuff. Go from 2WD to a 4WD with a simple move of a lever.
- Dual Pedal, 2 Range HST – Our MT125 model features the highly preferred dual pedal. Easier and more comfortable than rocker pedals and smoother switch.
- Independent PTO – Easiest PTO to operate that can be turned on or off with a switch.
- PTO Selector Switch – Allows you to select the rear-PTO, mid-PTO or both.
- Standard Mid PTO – 2000 RPM Mid PTO for optional 60" mid-mount mower or 50" front mount snow blower.
- Standard Hydrostatic Power Steering – Ditch the mechanical link—introducing hydrostatic power steering for ultimate flexibility, parts costs, and assemble-ability. This feature makes turning easier, improves control and reduces fatigue.
- Standard Foldable ROPS – Introducing foldable ROPS for storage allowance in low clearance buildings or sheds.
- 3-Point Hitch – Category 1 with a hitch lift capacity of 992 lbs. is smooth and responsive.
- Ergonomically Designed 3-Point Hitch Controls – Easily accessible for maximum comfort and convenience with hydraulic position control.
- Easily Adjust Mowing Height – Adjusting the cutting height for the available 60″ mid-mount mower is as easy as turning a dial.
- Toolbox – Convenient storage keeps tools handy.
- Yanmar Tier 4 Engine and Easy Open Hood – Tier 4 engine that provides reliable power and performance. Includes an Easy Open Hood for quick accessibility for easy maintenance.
- Modern Ergonomic Design – This small chassis compact is ergonomically designed and stylish.
- Comfortable High-Back Seat – Supportive and comfortable seat reduces fatigue and reverses position for backhoe use.
FRONT END LOADER — LL1700
- Maximum Lift Height (in.): 74
- Clearance with Attachment Dump (in.): 55
- Overall Height in Carry Position (in.): 41
- Lift Capacity (@ Pivot Pin) (lbs.): 980
- Breakout Force (@ Pivot Pin) (lbs.): 1,470
WARRANTY Some companies make you pay extra for an extended warranty. LS Tractor offers a 6-year limited powertrain warranty, including parts and labor, on most of the tractors we sell. 2-year bumper to bumper* protection that comes with every LS Tractor. There's no deductible, and not a lot of exclusions. Compare our short, easy to understand, no-nonsense warranty to the others and see for yourself that LS Tractor has you covered.
ENGINE
- Type: 3-cylinder, Indirect-injection, Water-cooled
- Model (Tier 4): Yanmar 3TNV80F
- Engine HP (Gross): 24.7
- PTO HP: 17.2
- Rated Speed (RPM): 3,000
- Displacement (cu in.): 77.3
- Fuel Tank Capacity (gal): 6.6
- Alternator (V-A): 12V – 40
DRIVE TRAIN
- Transmission: Hydrostatic Drive
- No. of Speeds: 2 Ranges
- Brakes: Wet, Multi-Disc
- Steering: Hydrostatic Power Steering
PTO
- Type: Independent
- Mid PTO: Standard (2500 rpm)
- Rear PTO: Standard (540 rpm)
HYDRAULIC SYSTEM
- Implement pump (gpm): 4.6
- Steering pump (gpm): 2.1
- Total flow (gpm): 6.7
- Category, 3 pt hitch: CAT 1
- Hitch lift Capacity (lbs.) (Hitch End): 992 (728 @ 24")
- Lift control type: Position
DIMENSION
- Overall length (Bumper to link, in.): 97
- Wheelbase (in.): 56
- Min. overall width with IND tires (in.): 47
- Height to top of ROPS (in.): 87
TIRE SIZE
- Agricultural Front/Rear: 18×18.5 – 10/26 x 12.0 – 12
- Versa Turf Front/Rear: 18×18.5 – 10/26 x 12.0 – 12
WEIGHT
- Total weight without ballast (lbs.): 1,444
